Rohde & Schwarz CMU 200 Service Manual

R&S CMU Test Report
1100.4903.82 1.27 E-5
Item
No.
Description
Measure-
ment
to section
Min. Actual Max.
Measurement
uncertainty
Unit
TX In-band spurious
R&S CMU setting = 2170.5 MHz
search freq. ± (5 to 500) kHz from
carrier
–40 dBc
TX Fixed Spurious Responses
TX fixed spurious,
R&S CMU setting = 14.35 MHz
search freq. 13.85 MHz
Level = –20 dBm
TX fixed
spurious
–40 dBc
TX fixed spurious,
R&S CMU setting = 37.4333 MHz
search freq. 36.9333 MHz
Level = –20 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 42.05 MHz
search freq. 41.55 MHz
Level = –20 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 111.3 MHz
search freq. 110.8 MHz
Level = –20 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 222.1 MHz
search freq. 221.6 MHz
Level = –20 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 332.9 MHz
search freq. 332.4 MHz
Level = –20 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 501.87 MHz
search freq. 501.37 MHz
Level = –20 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 1330.1 MHz
search freq. 1329.6 MHz
Level = 0 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 100 MHz
search freq. 1917.12 MHz
Level = 0 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 1300 MHz
search freq. 2142.08 MHz
Level = 0 dBm
–40 dBc
TX fixed spurious,
R&S CMU setting = 2200 MHz
search freq. 3042.08 MHz
Level = 0 dBm
–40 dBc
