Roland GX-24 User Manual

Chapter 7: Appendix
64
7-1 Usable Materials
Conditions for Usable Materials
Loadable material width
50 to 700 mm (2 to 27-1/2 in.)
Loadable material length
Flat Material: 100 mm (3-15/16 in.) or more
Roll Material: no restriction
A) Cuttable material thickness
Material-portion thickness of 0.1 (0.004 in.) mm or less
B) Maximum media thickness (including backing paper)
0.3 mm (0.012 in.) or less
(Material measuring up to 1.0 mm (0.039 in.) can be loaded.)
AB

Roland GX-24 Specifications

General

Cutting Speed	Up to 20 inches/sec (500 mm/sec)
Distance Accuracy	±0.004 inches (±0.1 mm) or less
Repeatability	±0.1 mm (0.0004 in.) or less
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5 to 40°C (41 to 104°F)
Operating Humidity	35 to 80% RH (non-condensing)
Software Resolution	0.025 mm/step (0.001 in./step)
