Roland Jupiter-80 - Plane View (1) Parts List

13
Jun. 2011 JUPITER-80
Plane View (1) Parts List
View 1
View 2
View 3
No. Part Code Part Name Description Q’ty
1 5100021415 STAND CAUTION LABEL 1
a 40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 5
b 40233012 SCREW 2.6X8 BINDING TAPTITE P BZC 4
c 40011101 SCREW 3X8 BINDING TAPTITE B BZC 3
d 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 2
e 40019123 SCREW 3X8 BINDING TAPTITE S BZC 1
f 40238501 SCREW 4X8 BINDING TAPTITE P FE BZC 2
g 40011745 HEX NUT M4 FE ZC 2
No. Part Code Part Name Description Q’ty
h 40010734 SCREW 3X12 BINDING TAPPING A FE ZC 4
i 40127545 SCREW 4X10 TRUSS TAPPING A FE BZC 7
k 40342456 SCREW 4X16 PAN WASHER HEAD TAPTITE B BZC 29
No. Part Code Part Name Description Q’ty
c 40011101 SCREW 3X8 BINDING TAPTITE B BZC 2
m 40011067 SCREW 3X8 BINDING TAPTITE B FE ZC 4
