Jun. 2011 JUPITER-80
Plane View (3)
fig.bunkaizu-3.eps
View 6
View 7
View 8
o
n
n
View 6
View 8
View 7
3
No. Part Code Part Name Description Q’ty
3 40122434 DOUBLE-FACED TAPE #500 W7MM 20M 30P -
o 40010645 SCREW 4X8 TRUSS TAPPING A FE BZC 2
No. Part Code Part Name Description Q’ty
n 40011056 SCREW 3X6 BINDING TAPTITE B ZC 10
No. Part Code Part Name Description Q’ty
n 40011056 SCREW 3X6 BINDING TAPTITE B ZC 9
