Roland Jupiter-80 Service Notes

25
Jun. 2011 JUPITER-80
Exploded View (Fig.F, G) Parts List
Fig.F
View F1
Fig.G
View G1
View G2
No. Part Code Part Name Description Q’ty
F1 5100020233 PWB HOLDER MAIN 1
F2 5100019999 FERRITE-CORE ESD-FPL-35-8 1
F3 5100020030 MAIN BOARD ASSY 1
No. Part Code Part Name Description Q’ty
n 40011056 SCREW 3X6 BINDING TAPTITE B ZC 9
No. Part Code Part Name Description Q’ty
G1 5100005906 SWTNG REG RLM50W REV.B 1
G2 01455523 CORD BUSHING EDS-1717U 1
G3 04902678 POWER SUPPLY HOLDER 1
No. Part Code Part Name Description Q’ty
G4 5100005900 SEAL IEC GND SEAL #5017 (W) 1
s 40012867 SCREW M3X8 PAN MACHINE W/SW+PW ZC 6
No. Part Code Part Name Description Q’ty
t 40017934 SCREW M3X6 PAN MACHINE W/SW+PW(L) FE ZC 6
u 40560723 STANDOFF M3-L5.5-H10 6

Roland Jupiter-80 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Reverberation
Keyboard number of keys	76
Maximum polyphony (notes)	256
Headphone outputs	1
USB ports quantity	2
6.35 mm (1⁄4-inch) output	6
Display type	LCD
Power source type	AC

Weight and Dimensions

Depth	439 mm
Width	1231 mm
Height	140 mm
Weight	17700 g
