Roland Jupiter-80 - Plane View (2) Parts List

15
Jun. 2011 JUPITER-80
Plane View (2) Parts List
View 4
View 5
No. Part Code Part Name Description Q’ty
1 05012101 CLAMP RFC-21V0 1
2 5100021495 LOCKING CLAMP RLWC-3SV0 1
3 40567623 DOUBLE-FACED TAPE #575 W15MM 30M -
4 40122434 DOUBLE-FACED TAPE #500 W7MM 20M 30P -
d 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 13
m 40011067 SCREW 3X8 BINDING TAPTITE B FE ZC 59
n 40011056 SCREW 3X6 BINDING TAPTITE B ZC 4
No. Part Code Part Name Description Q’ty
4 40122434 DOUBLE-FACED TAPE #500 W7MM 20M 30P -
5 40122490 DOUBLE-FACED TAPE #500 W5MM 20M 40P -
