Roland Jupiter-80 Service Notes

4
Jun. 2011 JUPITER-80
Location of Controls (Top, Front)
fig.panel.eps@L
9
10
34
33
8
4
6 7
19
20 21
11 24 2522 3223 26
1
2
3
5
40 41
Top Panel
Front Panel

Roland Jupiter-80 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Reverberation
Keyboard number of keys	76
Maximum polyphony (notes)	256
Headphone outputs	1
USB ports quantity	2
6.35 mm (1⁄4-inch) output	6
Display type	LCD
Power source type	AC

Weight and Dimensions

Depth	439 mm
Width	1231 mm
Height	140 mm
Weight	17700 g
