Roland Jupiter-80 Service Notes

3
Jun. 2011 JUPITER-80
Others
Arpeggiator
Preset: 128 styles
User: 128 styles
Harmony Intelligence
17 types
Controllers
D Beam Controller
Pitch Bend/Modulation Lever
Assignable buttons ([S1], [S2])
Assignable knobs ([E1]–[E4])
PART LEVEL sliders (PERC, LOWER, UPPER, SOLO)
Display
Graphic Color LCD 800 x 480 dots (touch screen)
Connectors
PHONES jack (stereo 1/4-inch phone type)
MAIN OUT jacks (L, R) (XLR type)
MAIN OUT jacks (L/MONO, R) (1/4-inch TRS phone type)
SUB OUT jacks (L, R) (1/4-inch phone type)
AUDIO IN jack (Stereo miniature phone type)
DIGITAL AUDIO OUT jack (COAXIAL)
FOOT PEDAL jacks (CTRL 1, CTRL 2, HOLD)
MIDI Connectors (IN, OUT, THRU)
USB COMPUTER port (Audio/MIDI)
USB Memory port
AC IN jack
Power Consumption
25 W
Dimensions
1,230.9 (W) x 439.3 (D) x 139.6 (H) mm
48-1/2 (W) x 17-5/16 (D) x 5-1/2 (H) inches
Weight
17.7 kg / 39 lbs 1 oz
Accessories
Owner’s Manual (#5100020682)
CD-ROM (USB Audio/MIDI driver) (#********)
DVD-ROM (SONAR LE) (#********)
USB MEMORY Protector (#5100005713)
Power Cord (#5100012292, #00894378, #03450323, #00894389, #00907001,
#5100013842)
Options (sold separately)
Keyboard stand: KS-18Z, KS-G8 (Use a stand that causes the height of the
unit to be one meter or lower.)
Pedal switch: DP series
Footswitch: BOSS FS-5U
Expression pedal: EV-5
Stereo Headphones
USB Flash Memory
* Printed matters will not be supplied after the end of the production. Then,
download the electronic file from the Roland web site.
* In the interest of product improvement, the specifications and/or appearance of
this unit are subject to change without prior notice.

Roland Jupiter-80 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Reverberation
Keyboard number of keys	76
Maximum polyphony (notes)	256
Headphone outputs	1
USB ports quantity	2
6.35 mm (1⁄4-inch) output	6
Display type	LCD
Power source type	AC

Weight and Dimensions

Depth	439 mm
Width	1231 mm
Height	140 mm
Weight	17700 g
