Roland Jupiter-80 Service Notes

6
Jun. 2011 JUPITER-80
Location of Controls (Top, Front) Parts List
Top Panel
No. Part Code Part Name Description Q’ty
1 5100017578 TOP PANEL 1
2 5100001159 SUB-ASSY USB BOX GW-8 (LF) (990-07040-10-04) 1
3 5100020256 Y S-KEYTOP LD3H BLK 2
13169711 TACT SWITCH SKPDALD010 6
02125167 LED SLI-343DCT32W 6
4 5100020679 M R-KNOB KF-ELA BLK/LCG 1
13289189 POTENTIOMETER RK14K1240A2D L1=15 50KBX2 1
5 02010434 Y S-KEYTOP LD4H BLK 1
13169711 TACT SWITCH SKPDALD010 4
02125167 LED SLI-343DCT32W 4
6 02016445 Y S-KEYTOP LD1H BLK 1
13169711 TACT SWITCH SKPDALD010 1
03904323 LED (BLUE) SLR-343BCTT32 1
7 02016445 Y S-KEYTOP LD1H BLK 2
13169711 TACT SWITCH SKPDALD010 2
02125167 LED SLI-343DCT32W 2
8 02016445 Y S-KEYTOP LD1H BLK 4
13169711 TACT SWITCH SKPDALD010 4
04902023 LED (RED/GREEN) SPI-325MUWT31 4
9 22485295 D S-KNOB S BLK/LCG 4
04897256 SLIDE POTENTIOMETER RS45111-0A10-C0-P1-B103 4
5100020229 D S-ESCT SX4H-C L=45 BLK 1
5100021485 POT DUST COVER 1
10 5100020230 LED COVER 4
03788578 LED DD-12HWB (H/I RANK) 4
11 02011412 Y S-KEYTOP SD1H BLK 5 1 included in Panel-C,
2 included in Panel-R,
1 included in Tone-L,
1 included in Tone-R Board
01340290 TACT SWITCH EVQ11A H=5.0 5
02125167 LED SLI-343DCT32W 5
12 5100016996 M R-KNOB LF BLK MNP 4
01905467 ROTARY ENCODER EVE GC1 F20 24B 4
13 02011456 Y S-KEYTOP SX1H BLK 6 1 included in Panel-C,
5 included in Panel-R Board
01340290 TACT SWITCH EVQ11A H=5.0 6
14 5100016526 LCD LQ070Y3DG3B 1
5100020246 LCD CUSHION 3
15 5100020228 LCD ESCT 1
5100020955 LCD TAPE 2
16 04565478 KNOB ZE R-KNOB LF 1
01905467 ROTARY ENCODER EVE GC1 F20 24B 1
04566445 KEYTOP ZE CURSOR KEY A 1
04566456 KEYTOP ZE CURSOR KEY B 1
02781634 TACT SWITCH SKRGAED010 4
05010278 KEYTOP COVER 1
40232134 ACETATE TAPE NITTO #5 BLACK W5MM 20M -
17 02016390 Y S-KEYTOP LX1H BLK 3
13169711 TACT SWITCH SKPDALD010 3
18 02016445 Y S-KEYTOP LD1H BLK 1
13169711 TACT SWITCH SKPDALD010 1
01239867 LED (RED/GREEN) CLR SML72423C TP15 1
19 01343089 ESCUTCHEON D-BEAM CONTROLLER ESCT BLK 1
20 01900612 DIODE TPS611(F) 1
12169368 LED SPACER LDS-40B 1
21 03126134 LED (INFRARED) TLN233(F) 1
02230578 LED SPACER LDS-50R 1
22 02016456 Y S-KEYTOP LD2H BLK 1
13169711 TACT SWITCH SKPDALD010 2
02125167 LED SLI-343DCT32W 2
23 02016501 Y S-KEYTOP LD2H MCG 1
13169711 TACT SWITCH SKPDALD010 2
02125167 LED SLI-343DCT32W 2
24 5100023704 RUBBER SW 1H-A RED 1
5100019647 LED TLRMK1100C(T11) 1
5100020325 ESCUTCHEON 3H 1/3
25 5100023706 RUBBER SW 2H-A ORN 2
5100019648 LED TLOK1100C(T11) 4
5100020325 ESCUTCHEON 3H 4/3
26 5100023707 RUBBER SW 2H-A YEL 2
5100019378 LED TLWF1100C(T11) 4
5100020325 ESCUTCHEON 3H 4/3
27 5100023709 RUBBER SW 3H-A WHT 1
5100019378 LED TLWF1100C(T11) 3
5100020325 ESCUTCHEON 3H 1

Roland Jupiter-80 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Reverberation
Keyboard number of keys	76
Maximum polyphony (notes)	256
Headphone outputs	1
USB ports quantity	2
6.35 mm (1⁄4-inch) output	6
Display type	LCD
Power source type	AC

Weight and Dimensions

Depth	439 mm
Width	1231 mm
Height	140 mm
Weight	17700 g
