Roland JUPITER-X User Manual

JUPITER-X Owner’s Manual Ver. 3.0 and later
12
Turning the JUPITER-X On
1. Power-on the equipment in the order of JUPITER-X
0
connected devices.
* In order to protect its circuitry, the JUPITER-X waits for a while after being
powered-on before it begins operating.
2. Switch on power to the connected equipment, and raise the
volume to an appropriate level.
* The power to this unit will be turned off automatically after
a predetermined amount of time has passed since it was
last used for playing music, or its buttons or controls were
operated (Auto Off function).
If you do not want the power to be turned off automatically, disengage the
Auto Off function.
&
“Making the Power Automatically Turn Off After a Time (Auto Off)” (p. 12)
5
Unsaved data is lost when the power turns off. Before turning the power off,
save the data that you want to keep.
5
To restore power, turn the JUPITER-X on again.
Turning Off the Power
1. Power-off the equipment in the order of the connected
devices
0
JUPITER-X.
* If you need to turn off the power completely, first turn off the unit, then
unplug the power cord from the power outlet.
Refer to “To completely turn off power to the unit, pull out the plug from
the outlet” (p. 2).
Making the Power Automatically Turn Off
After a Time (Auto Off )
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM”, and then press the
[ENTER] button.
You can also make this selection by using the PAGE [ ] [ ] buttons
instead of the [1] knob.
3. Use the [1] knob to select “GENERAL”, and then press the
[ENTER] button.
4. Use the [1] knob to select “Auto Off” and use the [2] knob to
change the setting.
If you don’t want the unit to turn off automatically, choose “OFF”
setting.
Parameter
[1] knob
Value
[2] knob
Auto Off
OFF, 30 [min], 240 [min]
5. To save the setting, press the [WRITE] button.
The save page appears.
If you decide to cancel, press the [EXIT] button.
6. To execute, press the [ENTER] button.
Adjusting the Overall Volume (Master Volume)
Adjusts the overall volume.
1. Adjust the [VOLUME] knob.
Using the Built-In Speakers
This unit contains built-in stereo speakers. If the built-in speakers are
turned on, you can play sound from this unit.
Speaker locations
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM”, and then press the
[ENTER] button.
You can also make this selection by using the PAGE [ ] [ ] buttons
instead of the [1] knob.
3. Use the [1] knob to select “GENERAL”, and then press the
[ENTER] button.
4. Use the [1] knob to select “Speaker Sw”, and use the [2]
knob to specify “ON” or “AUTO”.
Parameter
[1] knob
Value
[2] knob
Explanation
Speaker Sw
OFF Sound is not output from the speakers.
ON Sound is output from the speakers.
AUTO
“OFF” if headphones are connected,
“ON” if headphones are not connected.

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
