Introduction
Placing the JUPITER-X on a Stand
If you want to place the JUPITER-X on a stand, use the Roland KS-10Z or KS-12. Place the JUPITER-X on the stand as follows.
Be sure to follow the instructions in the Owner’s Manual carefully when placing this unit on a stand. If it is not set up properly, you risk creating an
unstable situation which could lead to the unit falling or the stand toppling, and may result in injury.
* Be careful not to pinch your fingers when setting up the stand.
KS-10Z
Adjust the horizontal width of the
stand as shown in the illustration.
Top view
Adjust so that the height
does not exceed 1 meter.
Align the front of the
JUPITER-X with the front of
the stand.
680 mm
KS-12
Adjust the width of the stand
so that the rubber feet on the
keyboard side of the bottom of
the keyboard fit into the holes
provided for the rubber.
Top view

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
