Roland JUPITER-X User Manual

14
Selecting and Playing Tones (MODEL BANK)
Selecting a Tone
In MODEL BANK mode, you can change the model or tone, or select
tones from models registered in a model bank ([1]–[16] buttons).
* You can also select using tone categories.
Playing the MODEL BANK Tones (SINGLE SETUP)
When SINGLE SETUP is executed, only part 1 is enabled, and you can
perform with the tones of only one model.
1. Hold down the [SHIFT] button and press the [MODEL BANK]
button.
A confirmation message for executing SINGLE SETUP is shown.
2. Press the [ENTER] button to execute SINGLE SETUP.
* You can also execute SINGLE SETUP from the MENU screen ([MENU]–
[EDIT]–[SINGLE SETUP]).
3. Press the [MODEL BANK] button.
4. Use the [1]–[16] buttons to select a model/category, and
use the [2] knob to select a tone.
Useful functions for selecting tones on the MODEL BANK
screen
5
Press the [ENTER] button to select a tone from the tone list screen.
5
Press the [ENTER] button to confirm.
5
Press the [EXIT] button to return to the tone you were using before the tone list
screen was displayed.
5
Press the PAGE [
ä
] button to move the cursor up.
5
You can use the [2] knob to select a model or category.
5
Press the PAGE [
å
] button to go back to selecting a tone.
* When SINGLE SETUP is executed, the scene data you were editing is lost.
Save the data if you want to keep it before executing SINGLE SETUP.
&
“Saving a Scene” (p. 13)
* The parameters that work with the controllers on this instrument differ
with each model. Refer to “Correspondence Between Controllers and
Parameters” in the “Reference Manual” for details.
* The SINGLE SETUP state is canceled when you switch scenes.
* You can also execute SINGLE SETUP from the MENU screen ([MENU]–
[SINGLE SETUP]).
Selecting Tones from a Model Bank
1. Press the [MODEL BANK] button.
You switch to tone select mode.
2. Press a [1]–[16] button to select a model bank.
Now you can select tones of the model that is registered in the
model bank.
3. Use the [2] knob to select a tone.
You can use the [1] knob to move rapidly.
MEMO
The models registered in the model banks can be assigned freely.
1. Hold down the [MODEL BANK] button and press the button
([1]–[16]) that you want to assign.
2. Press the PAGE buttons to move the cursor to “Attr”.
3. Select whether to assign MODEL, CATEGORY or USER.
4. Move the cursor to “Mdl**” and select the model name
(category name) to make the assignment.
* Up to eight models or categories can be assigned to a button.
* You can’t assign both models and categories to a button simultaneously.
5. If you want to save the setting, execute the System Write
operation.
&
“Saving the System Settings (System Write)” (p. 27)
Changing the Model or Tone from the Top
Screen
1. Press the [PART] button to switch to part select mode, and
then press a [1]–[5] button to select a part that you want to
change.
2. Press the [MODEL BANK] button.
The MODEL BANK top screen appears.
3. Press the PAGE [ ] button to move the cursor to the model/
category name.
4. Use the [2] knob to select a model/category.
5. Press the PAGE [ ] button to move the cursor to the tone
number.
6. Use the [2] knob to select a tone.
You can use the [1] knob to move rapidly.

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
