81
Chapter 5 Feature Reference
5-5 Optimizing Printing to Match Media Thickness
Adjusting Head Height to Match Media Thickness
Procedure
➊
Press .
Press
several times.
➋
Press .
➌
Open the front cover.
Move the lever to adjust the height of the head.
Moving the lever to "HIGH" makes a warning beep
sound twice. Moving it to "LOW" makes the warning
beep sound once.
➍
Close the front cover.
The print heads return to their original position and
the screen shown in the figure appears.
➎
Press .
Press
to go back to the original screen.
Description
Depending on the media, media may wrinkle or come loose from the platen during printing, increasing the chance of
contact with the print heads. When you are using such media, adjust the head height to "High."
Note that the height of the heads cannot be determined by just the thickness of the media.
Default Setting
[HEAD HEIGHT]: LOW
MENU
HEAD HEIGHT
HEAD HEIGHT
LOW
LOW
W 1839mm
SETUP SHEET
ROLL
Height-adjustment lever
Move firmly, until it stops.
MENU
HEAD HEIGHT
HIGH
LOW
