V-SYNTH
LOCATION OF CONTROLS
PARTS LIST
[PARTS]
[LED]
[SWITCH]
[POTENTIOMETER or ENCODER]
[SCREWS]
NO PARTCODE PART NAME DESCRIPTION Q’TY
1 01783956 N S-KEYTOP MD4H 2
2 03126856 D S-KEYTOP SX2H-B CLR 12
3,27 03126867 D S-KEYTOP SX1H-B CLR 13
4 03126878 D S-KEYTOP SX1H-B BLK 9
5 03126889 D S-KEYTOP SX2H-B BLK 1
6 03125589 M R-KNOB MF-ELA BLK/LCG 24
7 01561578 J S-KNOB S BLK/LCG 5
8 22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
9 03121112 DISPLAY ESCT 1
10 02895601 PAD ESCT 1
11 02895623 TWIN D-BEAM CONTROLLER ESCT 1
12 71905023 PB-H0203 BENDER TURBOLESS 1
13 72230178 LCD ASSY 1
14 72230189 XY-PAD ASSY 1
15 00569278 LGR4609-7100 6.5MM JACK 10
16 13429274 YKF51-5041 MIDI SOCKET 1
17 00458801 YKC21-3044 0/0 PIN JACK (ORG)PIN X 2 1
18 02565401 GP1FA501RZ OPTICAL CONNECTOR RX 1
19 02565390 GP1FA501TZ OPTICAL CONNECTOR TX 1
20 02781101 YKF45-0020 USB CONNECTOR 1
21 02896278 JC21EJ-FRM20 CARD CONECTR 1
22 02675701 WIRING ASSY WIRING W3
(AC INLET+GND)
1
23 32490595 P S-KEY MX BLK 1
24 02676878 EVUE20E15B14 9M/M ROTARY POTENTIOMETER 1
25 03121034 SLD-22-456A SLIDE SWITCH 1
NO PARTCODE PART NAME DESCRIPTION Q’TY
1~3 02125167 LED (YELOW) SLI-343DCT32W 48
26~28 03122112 LED SLR-343BBT3F 4
NO PARTCODE PART NAME DESCRIPTION Q’TY
23 01676512 PUSH SWITCH SDKLA1-B POWER SW 1
ALL 01340290 TACT SWITCH EVQ11A H=5.0 ALL TACT SWITCH 29
NO PARTCODE PART NAME DESCRIPTION Q’TY
6-A 02891878 9M/M ROTARY POTENTIOMETER RK09D1130 10KB 6
6-B 03122090 12M/M ROTARY POTENTIOMETER EVJ Y15 F01 A15 1
6-C 03122145 9M/M ROTARY POTENTIOMETER RK09D1130C3W 17
7-A 03122089 30M/M SLIDE POTENTIOMETER EWA NJO C15 B14 1
7-B 03122123 30M/M SLIDE POTENTIOMETER EWA NKE C15 B14 4
8 03122134 ROTARY ENCODER EC12E2420802 1
NO PARTCODE PART NAME DESCRIPTION Q’TY
a 40011490 SCREW M3X6 PAN MACHINE W/SW BZC 10
b 40011123 SCREW 4X8 BINDING TAPTITE B BZC 2
c 40010334 SCREW 4X8 BINDING BZC 1
d 40011312 SCREW 3X8 BINDING TAPTITE P BZC 5
To Next Page
