9
Mar.2003
PARTS LIST
fig.part1e
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CONSIDERATION ON PARTS ORDRING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts)
CASING
# 03120723 BOTTOM COVER 1
# 03126601 POT DUST COVER B 1
# 03126590 POT DUST COVER A 1
# 03126545 SIDE COVER R 1
# 03126534 SIDE COVER L 1
# 02895601 PAD ESCT 1
# 03121112 DISPLAY ESCT 1
# 02895612 CARD ESCT 1
# 03126556 END BLOCK 1
# 03126567 BENDER PANEL 1
# 02784778 TOP PANEL 1
CHASSIS
# 03120690 DISPLAY HOLDER 1
# 03120689 PWB HOLDER 2
02674034 PANEL HOLDER 2
02673956 SIDE HOLDER L 1
02673967 SIDE HOLDER R 1
02674001 PWR SPLY HOLDER 1
KNOB, BUTTON
32490595 P S-KEY MX BLK 1
22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
# 03125589 M R-KNOB MF-ELA BLK/LCG 24
01561578 J S-KNOB S BLK/LCG 5
SWITCH
# 03121034 SLD-22-456A SLIDE SWITCH SW1 on Jack Board 1
01340290 EVQ11A H=5.0 TACT SWITCH SW22,SW10,SW6,SW7,SW19,SW21,SW3,S
W8,SW9,SW20,SW15,SW12,SW13,SW5,SW
14,SW4,SW16,SW17,SW11,SW1,SW18,SW2,
SW23 on Panel-L board,
23
+3
3
SW14,SW27,SW25,SW24,SW23,SW22,SW21
,SW20,SW19,SW18,SW17,SW29,SW15,SW2
8,SW13,SW12,SW11,SW10,SW9,SW8,SW7,S
W6,SW5,SW4,SW3,SW2,SW1,SW16,SW31,S
W32,SW33,SW30,SW26 on Panel-R Board
01676512 SDKLA1-B PUSH SWITCH SW2 on Inlet Board 1
JACK, EXT TERMINAL
00458801 YKC21-3044 0/0 PIN JACK (ORG)PIN X 2 JK502 on Main board 1
# 02896278 JC21EJ-FRM20 CARD CONECTR 1
02781101 YKF45-0020 USB CONNECTOR JK501 on Main board 1
13429274 YKF51-5041 MIDI SOCKET JK1 on Sub board 1
00569278 LGR4609-7100 6.5MM JACK JK1,JK3,JK4,JK5,JK6,JK7,JK2 on Jack Board
,JK2,JK4,JK3 on Sub board
3
+7
DISPLAY UNIT
# 72230178 LCD ASSY 1
NOTE: Replacement LCD ASSY should be made on a unit base.
POWER SUPPLY UNIT
01785823 A1DU2L3B034 SWITCHING REGULATOR 1
NOTE: Replacement A1DU2L3B034 should be made on a unit base.
To Next Page
