10
V-SYNTH
BENDER UNIT
71905023 PB-H0203 BENDER TURBOLESS 1
NOTE: Replacement PB-H0203 should be made on a unit base.
SPEAKER, BUZZER
15299147 PKM22EP-2001 BUZZER SP1 on Sub board 1
KEYBOARD ASSY
# 72232478 KEYBOARD ASSY SK-961-J 1
NOTE: See ‘KEYBOARD PARTS LIST’ for details.
PCB ASSY
# 72015023 MAIN TOTAL ASSY 1
NOTE: ‘MAIN TOTAL ASSY’ includes the following parts.
12199584 GROUNDING TERMINAL M1698 TER2,TER1,TER3 on Jack Board,TER501 on
Main board ,TER2,TER1 on Sub board
,TER4 on Inlet Board
1
# 40455878 SCREW M2X8 PAN MACHINE W/SW+PW
ZC
4
# 72230067 SUB BOARD ASSY 1
NOTE: ‘SUB BOARD ASSY’ includes the following parts.
12199584 GROUNDING TERMINAL M1698 TER2,TER1,TER3 on Jack Board,TER501 on
Main board ,TER2,TER1 on Sub board
,TER4 on Inlet Board
2
# 72230078 JACK BOARD ASSY 1
NOTE: ‘JACK BOARD ASSY’ includes the following parts.
12199584 GROUNDING TERMINAL M1698 TER2,TER1,TER3 on Jack Board,TER501 on
Main board ,TER2,TER1 on Sub board
,TER4 on Inlet Board
3
# 72230089 PANEL-L KEYTOP ASSY 1
NOTE: ‘PANEL-L KEYTOP ASSY’ includes the following parts.
# 02895623 TWIN D-BEAM CONTROLLER
ESCT
1
# 03126878 D S-KEYTOP SX1H-B BLK 2
# 03126856 D S-KEYTOP SX2H-B CLR 4
# 03126867 D S-KEYTOP SX1H-B CLR 5
01783956 N S-KEYTOP MD4H 2
12169406 LED SPACER 3
# 03233245 LED SPACER LH-5S-8.7 2
# 72230101 PANEL-R KEYTOP ASSY 1
NOTE: ‘PANEL-R KEYTOP ASSY’ includes the following parts.
# 03126878 D S-KEYTOP SX1H-B BLK 7
# 03126856 D S-KEYTOP SX2H-B CLR 8
# 03126867 D S-KEYTOP SX1H-B CLR 8
# 03126889 D S-KEYTOP SX2H-B BLK 1
02123012 ENCODER HOLDER 1
12169406 LED SPACER 5
# 72230134 INLET BOARD ASSY 1
NOTE: ‘INLET BOARD ASSY’ includes the following parts.
02675701 WIRING ASSY WIRING W3(AC INLET+GND) JK8 on Inlet Board 1
02678478 WIRING WIRING W1 CN26 on Inlet Board 1
12199584 GROUNDING TERMINAL M1698 TER2,TER1,TER3 on Jack Board,TER501 on
Main board ,TER2,TER1 on Sub board
,TER4 on Inlet Board
1
# 72230145 LCD BOARD ASSY 1
# 72230156 INVERTER BOARD ASSY 1
NOTE: ‘INVERTER BOARD ASSY’ includes the following parts.
40342856 COATING CLIP CP-1S 2
# 72230167 PAD BOARD ASSY 1
IC
# 02900678 HD6417297BP267 IC (32BIT CPU) IC6 on Main board 1
# 02900978 M66291GP IC (USB CONTROLLER) IC502 on Main board 1
02568478 M66273FP LCD-DRIVER IC501 on Main board 1
02231767 RA0A-101 (TC223C080AF-101) IC (DSP) IC22 on Main board 1
02782778 TC200E06 (PPC) IC (I/F) IC20 on Main board 1
02453389 LC32V4265T-25 IC (DRAM) IC24 on Main board 1
To Next Page
