11
Mar.2003
# 03235312 K4S561632
D-TC75
IC (DRAM) IC3,IC7 on Main board 2
02232367 HN58X2432FPI IC (EEPROM) IC11 on Main board 1
******** LH28F320BFE-PTBL80 IC (FLASH MEMORY) IC21 on Main board 1
******** NAND K9F5608U0B IC (FLASH MEMORY) IC509 on Main 1
02234167 AK4393-VF-E2 IC (DAC) IC546 on Main board 1
01679990 AK4524VF-E2 IC (AD/DA) IC542 on Main board 1
01348101 TTL TC7SET32FU(TE85L) IC (CMOS) IC551 on Main board 1
# 03015223 TC74LCX74FT(EL) IC (CMOS) IC2 on Main board 1
01121834 TC7W74FU TE12L IC IC537 on Main board 1
01121845 TC7W04FU TE12L IC (CMOS) IC534 on Main board 1
01349590 TC7WU04FU(TE12L) IC (CMOS) IC13,IC536 on Main board 2
01569689 TC7W32FU(TE12L) IC (CMOS) IC504 on Main board 1
15259706T0 TC74HCU04AF(EL) IC (HS-CMOS) IC532 on Main board 1
01348912 TC7SH08FU(TE85L) IC (CMOS) IC23,IC507 on Main board 2
01348945 TC7SH32FU(TE85L) IC (CMOS) IC32 on Main board 1
01455312 TC7WH74FU IC (CMOS) IC548 on Main board 1
01675023 TC74VHC139FT(EL) IC (CMOS) IC25 on Main board 1
01783523 TC74VHCT245AFT(EL) IC (CMOS) IC531,IC538,IC503 on Main board 3
01890367 TC74VHC175FT(EL) IC (CMOS) IC512 on Main board 1
02129334 TC7WH08FU(TE12L) IC (CMOS) IC14,IC524 on Main board 2
02451912 HD74LV00ATELL IC (CMOS) IC26,IC27,IC550 on Main board 3
02675656 HD74LV11ATELL IC (CMOS) IC505 on Main board 1
02675667 HD74LV21ATELL IC (CMOS) IC15 on Main board 1
02675689 HD74LV245ATELL IC (CMOS) IC8,IC1,IC539,IC9,IC4,IC5,IC525,IC527,IC1
0,IC533,IC526,IC523,IC522,IC520,IC12,IC51
9,IC18,IC16,IC17 on Main board
19
# 03015234 HD74LV32ATELL IC (CMOS) IC521,IC515,IC28 on Main board 3
03015389 TC74VHC153FT(EL) IC (CMOS) IC535 on Main board 1
# 03120834 TC74VHCT00AFT(EL) IC (CMOS) IC529 on Main board 1
# 03120856 TC74VHC273AFT(EL) IC (CMOS) IC517 on Main board 1
02897690 OP275GS IC (BIPOLAR OP) IC545 on Main board 1
15289117 NJM5532MD-TE1 IC (OP AMP) IC543,IC541 on Main board 2
00344390 TA7805F(TE16L) IC (REGULATOR) IC540,IC544 on Main board 2
# 02900734 XC6365A333MR IC (DC/DC) IC506 on Main board 1
# 02900745 XC6365B103MR IC (DC/DC) IC19 on Main board 1
02236978 CS8420-CS IC (DIGITAL I/F CODEC) IC530 on Main board 1
# 03120878 AAT4650IHS-T1 IC IC549 on Main board 1
15199937 M51953BFP-600C IC (RESET) IC508 on Main board 1
02565390 GP1FA501TZ TX IC (OPTICAL CONNECTOR) CN508 on Main board 1
02565401 GP1FA501RZ RX IC (OPTICAL CONNECTOR) CN507 on Main board 1
# 03127267 HD6433061G45FP IC (16BIT CPU) IC2 on Sub board 1
00129278 SSC1080F0B IC IC5 on Sub board 1
02893945 HD74LV05AFPEL IC (CMOS) IC19 on Sub board 1
# 03120990 HD74LV4051AFPEL IC (CMOS) IC11 on Sub board 1
# 03121001 HD74LV4053AFPEL IC (CMOS) IC12 on Sub board 1
00232634 TC7W74F(TE12L) IC IC6 on Sub board 1
15249121 TC7W04F(TE12L) IC (CMOS) IC13 on Sub board 1
15259704H0 HD74HC138FPEL IC (HS-CMOS) IC15,IC16 on Sub board 2
15259708T0 TC74HC08AF(EL) IC IC14 on Sub board 1
15289128 BA10324AF IC (OP AMP) IC18 on Sub board 1
15289151 NJM2904M-TE3 IC (OP AMP) IC5,IC8 on Panel-L board ,IC7,IC10 on Sub
board
2
+2
00458312 NJM2360M IC (REGULATOR) IC20 on Sub board 1
02900545 PC410LKNIP IC (PHOTO COUPLER) IC17 on Sub board 1
15189248 M5216P IC (BIPOLAR OP AMP) IC1 on Jack Board 1
15189266 NE-5532AN IC (BIPOLAR OP AMP) IC2 on Jack Board ,IC7,IC6 on Panel-L board 1
+2
01016678 TC7W241FU(TE12L) IC (CMOS) IC4 on Panel-L board 1
02017034 TC7W53FU(TE12L) IC (CMOS) IC3 on Panel-L board 1
15289105 UPC4570G2-E2 IC (BIPOLAR OP AMP) IC1,IC2 on Panel-L board 2
01896056 HD74HC4051P IC (CMOS) IC1,IC2,IC3 on Panel-R Board 3
15189249 BA10324A IC (OP AMP) IC4 on Panel-R Board 1
15189185 M5223AL-600Y IC (OP AMP) IC3 on Pad Board,IC6 on Lcd Board 1
+1
IC
TRANSISTOR
# 02900778 PW MOSFET XP132A1275SR TRANSISTOR Q1,Q501 on Main board 2
01121278 2SA1576A T106 QRS TRANSISTOR Q504 on Main board 1
00239812 DTC114EUT106 TRANSISTOR Q505,Q506,Q509 on Main board
,Q23,Q19,Q18,Q17,Q16,Q15,Q14,Q13,Q12
on Sub board
3
+9
01121289 2SC4081 T106 QRS TRANSISTOR Q2,Q1 on Panel-L board ,Q25,Q1,Q2,Q3 on
Sub board
4
+2
00239801 DTA114EU T-106 TRANSISTOR Q20 on Sub board 1
01783612 RN2426(TE85L) TRANSISTOR Q26,Q6,Q7,Q8,Q9,Q11,Q27,Q10 on Sub
board
8
15129152 2SC2878-A(TPE2) TRANSISTOR Q5,Q3,Q6,Q7,Q8,Q2 on Jack Board 6
15139124 2SK363-GR(TPE2) TRANSISTOR Q4,Q1 on Jack Board 2
00562012 2SC3265-Y(TE85R) TRANSISTOR Q4,Q3 on Panel-L board 2
15129151 2SC1815-GR(TPE2) TRANSISTOR Q30 on Lcd Board 1
To Next Page
