Roland VersaCamm VS-640 User Manual

Accommodating to the Types and Condition of Media
4
Part of Practice
108
Using Transparent Media
Procedure

Press .

Press several times to display the left gure.
Press
twice.

Press to select “DISABLE.”
Press
to enable the setting.
The settings are changed and the screen shown in the gure appears.
Description
This setting enables or disables detection of the leading and trailing edges of the media. It is normally set to
"ENABLE." When transparent media is loaded, set it to "DISABLE." When [EDGE DETECTION] is set to "DISABLE,"
printing operation does not stop when the media runs out. If media runs out while printing is in progress, im-
mediately press
to quit printing. Otherwise, there is a chance that the platen or the like may become
soiled by ink or that ink may get inside and damage the machine.
Default Setting
[EDGE DETECTION]: ENABLE
Printing Hard-to-dry Media
Procedure

Press .

Press several times to display the left gure.
Press
, and then .

Press .

Press to select a value.
Larger values produce progressively slower movement of the media, en-
abling you to extend the drying time accordingly
Press to enable the setting.

Press to go back to the original screen.
MENU
SUB MENU
EDGE DETECTION
ENABLE DISABLE
SETUP SHEET
MENU
SUB MENU
SUB MENU
SCAN INTERVAL
SCAN INTERVAL
OFF 1.0 sec
W1200mm
SETUP SHEET
108

Roland VersaCamm VS-640 Specifications

General

Print Technology	Piezo inkjet
Resolution	Maximum 1440 dpi
Interface	Ethernet (10BASE-T/100BASE-TX), USB 2.0
Power Requirements	AC 100 to 240 V ± 10%, 50/60 Hz
Media Width	64 inches
Cutting Speed	11.8 in/s
Ink Configuration	CMYK, Light Cyan, Light Magenta, White
Media Handling	Roll
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Metallic Silver, White
Media Thickness	Maximum 39 mil
Maximum Print Width	64 in (162.5 cm)
