Loading Media
44
Performing the Initial Adjustment (Correcting for Misalignment in Bidirectional Printing More Precisely)
Perform the initial adjustment (correction for misalignment in bidirectional printing more precisely) of this
machine. In the following case, perform this adjustment.
 When using this machine for the rst time
 When changing the media to use for the rst time
 When further correction is required to improve printing, such as when simple correction is performed for
misalignment in bidirectional printing. P. 104, "Correcting for Misalignment in Bidirectional Printing"
Procedure

Press .

Press several times to display the left gure.
Press
, and then .

Press .

Press .
A test pattern is printed.
When printing ends, then press .

Press .

Press to select a correction value of No.1.
Press
.
Press
to select a correction value of No.2.
Press
.
MENU
ADJUST BI-DIR
ADJUST BI-DIR
DETAIL SETTING
DETAIL SETTING
TEST PRINT
ADJUST BI-DIR
DETAIL SETTING
NO.1 NO.2
‑ 6 ‑ 4
To decide a Correction Value
Choose the value that produces the least misalignment of 2lines.
H1
NO.1
H1
NO.2
H1
NO.3
H1
NO.4
H1
NO.1
Correction-value scale
Choose the value that produces
the least misalignment.
Current correction value
2
Basic Operation

Roland VersaCamm VS-640 Specifications

General

Print Technology	Piezo inkjet
Resolution	Maximum 1440 dpi
Interface	Ethernet (10BASE-T/100BASE-TX), USB 2.0
Power Requirements	AC 100 to 240 V ± 10%, 50/60 Hz
Media Width	64 inches
Cutting Speed	11.8 in/s
Ink Configuration	CMYK, Light Cyan, Light Magenta, White
Media Handling	Roll
Ink Colors	Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Metallic Silver, White
Media Thickness	Maximum 39 mil
Maximum Print Width	64 in (162.5 cm)
