Electrical Specification
Rated Output 1 x 3.6kW 1 x 7.2kW 2 x 3.6kW 2 x 7.2kW
Input Voltage 230VAC / 50Hz (Single Phase)
Product Code OCPP0412 OCPP0410 OCPP0422 OCPP0423
Rated Output 1 x 11kW 1 x 22kW 2 x 11kW 2 x 22kW
Input Voltage 400VAC / 50Hz (3 Phase)
1x C20A MCB 1x C40A MCB 2x C20A MCB 2x C40A MCB
AC & DC Fault Protection 1x Type B RCD 2x Type B RCD
1 x IEC 62196 (Type 2) 2 x IEC 62196 (Type 2)
Charge Protocol
Mode 3
GPRS / Ethernet requires connection to a back-office application.
x GPRS
Requires a signal strength of 14 CSQ or better.
Units are supplied with their SIM cards pre-installed.
x
Require a suitable RJ45 ethernet cable to be connected for EACH socket that will be
used.
Incoming Cable Terminals 3x 50mm (Single Phase) or 5x 50mm (Three Phase)
Certifications and Compliances
This product has been designed and built in accordance with the following standards and legislation:
IET EV Reg’s, Glow Wire IEC 60695-2-13
EMC Compliance EN 301 489-01 V2.2.0, EN 301 489-03 V2.1.1,
EN 301 489-52 V1.1.0,
EN 50470-1:2006 (single socket units),
EN 55032:2015 (double socket units).
Safety Compliance EN 62368-1 :2014 (single socket units),
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
EN 62311:2008, EN 61851-1:2011 (double socket units).
Product Safety EN 62368-1:2014
Low Voltage Directive (LVD) 2014/35/EU
Radio Equipment Directive
Spectrum/ Telecom (Art. 3(2)):
2014/53/EU,
EN 301 511 V9.0.2, EN 300 330 v2.1.1
Electromagnetic Fields EN 62311:2008
Environmental Protection BS EN 60529:1992+A2:2013
x Enclosure IP66
x Socket IP54
Plug(s)/Socket(s) BS EN 62196-1:2014, BS EN 62196-2:2017
IK10 Impact Rating BS EN 62262
Fire Rating UL94 Flame Rating at V2 for 1.5mm and 3.0mm
RoHS 2011/65/EU
REACH 1907/2006
Eco Design 2009/125/EC
