3.4.9 FLOUR DUSTER
This accessory is only available as option for models R65 – R65T – R65-I and only when making the
purchase. Use the flour duster as described (refer to Figure 14):
• Remove lid Ref. 1 (option) and fill the hopper with flour (maximum capacity approximately 5.5 kg)
• It is possible to limit the width of the dusting area by operating on dividers Ref.2. To dust over the
whole length of the belt, the dividers must be fully open (pull in the direction indicated by the
arrow)
• Adjust the quantity of flour to be dusted by means of handwheel Ref. 3. Move it to the right to
increase quantity and to the left to reduce it and use the reference notches.
WARNING: we recommend not using flour with a high humidity level
• To operate the flour duster, keep the push-button Ref. 4 pressed down for as long as it is
necessary. Once the push-button is released, the flour duster will stop.
Figure 14
The flour duster hopper can be quickly removed to clean it or carry out maintenance operations.
Before assembling or disassembling the work tables, take the main switch to O (OFF) and unplug the
power plug, to prevent the machine from starting To correctly assemble the tables, two people must
operate as described hereafter and in accordance with Figure 15:
• Remove the lid Ref. 1 (option) and unscrew the two screws Ref. 5
• Close all the dividers Ref. 2 by pushing them to their stop (this operation prevents the flour from
coming out after having removed the hopper)
• The two operators, standing facing each other at the two sides of the machine, must lift the flour
duster using the corresponding handwheels, until it comes out from the head
• At this point it is possible to pour out any flour from the hopper and clean it
• Assemble the hopper by following the instructions given for disassembling, in the reverse order
Figure 15
