Rollmatic R62 - Safety Devices and Remarks

28
R62 / R62T / R65 / R65T - Rev. A
5.2.2 SAFETY DEVICES AND REMARKS
With reference to Figure 21 we hereby indicate the safety devices present on the machine:
• Mobile guards ref. 1 with safety microswitch ref. 2
• Flour collection drawer closing control microswitch ref. 3
• Emergency switch ref. 4
Figure 21
Fixed guards. They are all the protections that are fastened to the machine and that require the use
of at least one tool to remove them. With reference to Figure 21 we are mainly referring to the
following items already described in this manual:
• Front and back transmission guards ref. 5
• Electric board door ref. 6
• Fixed cutting station guard ref. 7 (to prevent access to the knife working area)
• Flour tray ref. 8 (to prevent access to the cylinders)
ATTENTION
It is strictly forbidden to open and/or remove the guards and/or disable the safety devices unless
it is absolutely necessary to carry out some operations and this is only possible after all measures
have been adopted to highlight the presence of consequent risks. These operations should only be
carried out if strictly necessary and should be limited in time; they must be carried out only and
exclusively by expert, trained and expressly authorized personnel. The safety devices must be
reset and the protections put back in place and fastened using the supplied means as soon as the
reason for their removal/disabling has stopped.
