19
Temp Units is one of the following:
ITEM MEANING
Deg C Degrees Celsius
Deg F Degrees Fahrenheit
DegR degrees Rankine
Kelvin degrees Kelvin
Linearization Menu
The X96S is capable of performing a multi-point linearization of the mass flow data when required by an application. The
linearization table contains thirty entries, numbered 1 through 30. Each entry consists of a measured (Ronan indicated) value, an
actual (physical) value, and a flag that indicates if the entry is used
4
.
The Linearization menu is used to control the linearization mechanism. It contains the following items:
ITEM FUNCTION
Linearize Shows the current state of the Linearization mechanism (enabled or disabled) and
allows the user to change the state.
Table Entry # Shows and allows the user to select an entry in the linearization table
Entry Used Shows if the entry is used or not.
Measured Shows and allows the user to set the displayed indicated value associated with this
linearization table entry. This is the nonlinear value calculated by the X96S when
linearization is disabled.
Actual Shows and allows the user to set the actual value associated with this linearization
table entry. This value is the physically measured value of the process.
Clear Table This item invokes a method that clears all entries in the linearization table.
Scan Time Menu
The Scan Time menu is used to configure the rate the input board scans the detector signal and the rate the microprocessor
updates the LCD display and the output signal.
Mass Flow
The Mass Flow menu is used to configure the parameters associated with the Rate measurement. It contains the following
items:
ITEM FUNCTION
Mass Flow Units Shows and allows the user to set the rate units used.
Calc. Dry Solids Shows and allows the user to set the dry solids calculations. Disabled = total mass
flow; Enabled = dry solids mass flow.
Low Range Shows and allows the user to set the rate value to be mapped to 4ma on the current
loop output, if rate is selected to control that current loop.
High Range Shows and allows the user to set the rate value to be mapped to 20ma on the current
loop output, if rate is selected to control that current loop.
4
Not all of the entries need to be used and the entries do not need to be used in any particular order.
