42
Mechanical Mounting
Review the Configuration Drawing which is
included in the Drawing Chapter of this manual.
Please reference the dimensional drawings located
in the Drawing Chapter of this manual when
installing the equipment.
Consider the following general guidelines when
mounting the sensor and detector:
Avoid internal vessel obstructions such as baffles,
agitators,
manways, heater/cooler tubes, etc. which could
interfere with the transmission through the vessel of
the radiation's "active beam."
The source and detector must be rigidly mounted so
they do not move with respect to each other. Such
movement will destroy the system's calibration
and/or its measurement.
Insulation must be used at the point of installation
IF:
- the temperature of the vessel at that spot exceeds
120
o
F (50
o
C), or - the voltage transmission through
the vessel could interfere with the signal
transmission from the source to the detector.
Drawings:
Configuration
Installation
Drawin
s
