Ronan Engineering X96S User Manual

21
Solids Setup
The Solids Setup menu contains the following items:
ITEM FUNCTION
Solids Method Shows and allows the user to set the method of measurement fixed or remote
Carrier Shows and allows the user to set the weight of the carrier
Solids Shows and allows the user to set the weight of the solids
Solubility Factor Shows and allows the user to set the solubility (multiplier)
Lo Solids Cap Shows the user the lo solids captured value
Hi Solids Cap Shows the user the hi solids captured value
Solids Counts Shows the user the number of counts being used (read only)
Curr. Solids Shows the user the current solids value
Min Solids Shows and allows the user to set the minimum solids weight
Max Solids Shows and allows the user to set the maximum solids weight
Flow Rate
The Flow Rate menu is used to configure the parameters associated with the Flow Rate measurement. It contains the following
items:
ITEM FUNCTION
Flow Rate Units Shows and allows the user to set the flow rate units used
Low Range Shows and allows the user to set the flow rate value to be mapped to 4ma on the
current loop output, if speed is selected to control that current loop.
High Range Shows and allows the user to set the flow rate value to be mapped to 20ma on the
current loop output, if speed is selected to control that current loop.
Flow Rate Units is one of the following:
ITEM MEANING
Cuft/s Cubic feet per second
Cuft/min Cubic feet per minute
cuft/h Cubic feet per hour
cuft/d Cubic feet per day
cum/s Cubic meters per second
cum/min Cubic meters per minute
cum/h Cubic minutes per hour
cum/d Cubic minutes per day
l/s Liters per second
l/min Liters per minute
l/h Liter per hour
gal/s Gallon per second
gal/min Gallon per minute
gal/h Gallon per hour
impgal/s Imperial gallon per second
impgal/min Imperial gallon per minute
impgal/h Imperial gallon per hour
impgal/d Imperial gallon per day
mgal/d Millions of gallons per day
ml/d Millions of liters per day
Proc Temp
The Proc Temp. Menu is used to configure the parameters associated with the process temperature measurement. It contains the
following items:
