Ronan Engineering X96S User Manual

13
Root Menu
The root menu is titled “Ronan X96S – Mass Flow”. It contains the following items:
ITEM FUNCTION
Variables Selecting this choice takes the user to the Variables menu.
Status Displays Selecting this choice takes the user to the Status Displays menu.
Configuration Selecting this choice takes the user to the Configuration menu.
Digital Outputs Selecting this choice takes the user to the Digital Outputs menu.
Digital Inputs Selecting this choice takes the user to the Digital Inputs menu.
Calibration Selecting this choice takes the user to the Calibration menu.
Reset Totalizer Selecting this choice allows the user to the Reset Totalizer .
Reset PD Cntr Selecting this choice allows the user to the Reset PD Cntr .
Diagnostic Selecting this choice takes the user to the Diagnostic menu.
Variables Menu
The menu titled “Variables” contains the following items:
ITEM FUNCTION
Variable Mapping Selecting this choice takes the user to the Variable Mapping menu.
PV Shows the current value of PV (the Primary Variable).
SV Shows the current value of SV (the Secondary Variable).
TV Shows the current value of TV (the Tertiary Variable).
QV Shows the current value of QV (the Quatrenary Variable).
Density Shows the current value of Rate (the Rate Variable).
Mass Flow Shows the current value of Mass Flow (the Mass Flow Variable).
Flow Rate Shows the current value of Flow Rate (the Rate of Flow Variable).
Proc Temp Shows the current value of Proc Temp (the Processed Temperature).
Head Temp Shows the current value of Head Temp (the Head Temperature).
Totalizer Shows the current value of Total Mass Flow (the Total Mass Flow Variable).
Raw Counts Shows the current value of Raw Counts (the Raw Counts Variable).
Filt Cnts Shows the current value of Filter Cnts (the Filter Counts Variable).
Variable Mapping Menu
The “Variable Mapping” menu allows the user to select the device variable to be mapped to PV, SV, TV, and QV. It contains the
following items:
ITEM FUNCTION
PV is Shows the device variable assigned to PV and allows the user to change the selection.
SV is Shows the device variable assigned to SV and allows the user to change the selection.
TV is Shows the device variable assigned to TV and allows the user to change the selection.
QV is Shows the device variable assigned to QV and allows the user to change the selection.
Each PV, SV, TV, and QV may each select one of the following:
SELECTION MEANING
Mass Flow Mass Flow (example: pounds per hour)
Density Density (example: pounds per gallon)
Flow Rate Flow Rate (example: feet per second)
Proc Temp Proc Temp (example: Deg F, Deg C, Deg R or Kelvin)
Head Temp Head Temperature (if Available)
Not Assigned Blank line
