Ronan Engineering X96S - Filtering and Compensation

12
Reset Totalizer
Reset PD Cntr
Diagnostic
Density
Density
Flow Rate
[Read Only]
Proc Temp Raw Density
%Mass Flow % Density
Solids
Filt Counts
Alarms
Last Ref. Date
Ref Density
Cal Density
Decay Ref Cap
Decay Cal Cap
Ref Cap
Cal Cap
1 u/T
Flow Rate
[Read Only]
Flow Rate Counts
% Flow Rate
Low Flow Rate
High Flow Rate
Ref.Capt.Value
Cal.Capt.Value
Pulse Factor
Solids
Lo Solids Cap [read only]
Hi solids Cap [read only]
Solids Counts [read only]
Curr. Solids [read only]
Min Solids [value]
Max Solids [value]
Alarms
[read only]
Sys. Alarm
Empty Clamp
Det. Fault
AutoCal Ref
AutoCal Error
Ref. Prompt
Wipe Test
Shutter Test
Alarms
Dig. Inputs
Figure 3-5 – Diagnostics Menu
