Ronan Engineering X96S User Manual

67
X96-2009PL2
X96-2009PL is the Scintillation Detector Interface Module. This optional
11
module provides:
• 1 isolated scintillation input (pulse counter, max signal 0-12
12
V, threshold 0.6 V)
• 1 head temperature input (1 uA per deg K)
• a 4-20 mA input (Ch. 2)
• isolated power for the scintillation detector 24 V 40 mA supply
13
.
X96-2009PL3
X96-2009PL is the Scintillation Detector Interface Module. This optional
14
module provides:
• 1 isolated scintillation input (pulse counter, max signal 0-12
15
V, threshold 0.6 V)
• 1 head temperature input (1 uA per deg K)
• a 0 –10 volt input (Ch. 2)
• isolated power for the scintillation detector 24 V 40 mA supply
16
.
11
At least one detector interface module is required.
12
8.6 V nominal.
13
The power supply has the ability to control the power to the scintillation detector:
• when commanded by the CPU module,
• when the processor on the module detects a condition that could harm the scintillation detector,
• when the watchdog timer generates a reset.
14
At least one detector interface module is required.
15
8.6 V nominal.
16
The power supply has the ability to control the power to the scintillation detector:
• when commanded by the CPU module,
• when the processor on the module detects a condition that could harm the scintillation detector,
• when the watchdog timer generates a reset.
