Temp Reference
This menu is used ONLY if the Hardware Menu, Proc Temp value is set for 0-10 volts or 4-2- ma
This menu is used to perform the process temperature reference procedure. It contains the following items:
ITEM FUNCTION
Temp LoRef This invokes a method that performs the low temp reference
Temp High Cal This invokes a method that performs the high temp reference
Temp. Cal Low Temperature value during the Temp Lo Ref procedure
Temp. Cal High Temp value during the Temp High Cal procedure
Temp Cap Low Shows the raw captured temperature counts during the low temp reference
Temp Cap High Shows the raw captured temperature counts during the high temp reference
RTD Slope Factory value for RTD Slope
RTD Offset Factory value for RTD Offset
Cal Remote Solids
This menu is used to calibrate the remote input. It contains for following items:
ITEM FUNCTION
Lo Solids Cap Shows the user the low solids captured counts
Hi Solids Cap Shows the user the high solids captured counts
Min Solids Shows and allows the user to input the minimum solids value
Max Solids Shows and allows the user to input the maximum solids value
Low Reference This invokes a method that performs the low reference procedure
Hi Calibration This invokes a method that performs the high calibration procedure
Loop Config Menu
This menu is used to access the primary 4-20ma loop calibration procedures. It contains the following items:
ITEM FUNCTION
Pv is Shows and allows the user to set the variable assigned to the primary 4-20mA current
loop
Loop test This item invokes a method that performs a test on the primary 4-20ma current loop
Damping Shows and allows the user to set the damping constant for the primary 4-20ma current
loop
D/A trim This item invokes method that performs the D/A trimming of the primary 4-20ma
current loop
PV is one of the following:
ITEM MEANING
Mass Flow Mass Flow (example: pounds per hour)
Density Density (example: pounds per linear foot)
Flow Rate Flow Rate (example: feet per second)
Head Temp Head Temperature (if Available)
Not Assigned Blank line
To Next Page
