Ronan Engineering X96S User Manual

57
Quick Start Reference – Calibrating Flow Rate
(For Completion of a Single Point Reference)
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Main Menu
Variables
Status Display
Configuration
Digital Outputs
Digital Inputs
→
Calibration .
Dia
g
nostics
Step 1 Low Reference Flow Calibration
(Have a “0” flow input ready)
Scroll down ↓ to “Calibration” Press → to enter menu
Scroll down ↓ to “Cal Flow Rate” Press the → to enter menu
Scroll down ↓ to “Low Reference” Press the → to enter menu
Select “Low Flow Rate Cal” press → to enter menu
Read the next screen carefully and acknowledge by pressing the F4
(OK) Key. Referencing will begin. (This may take several minutes.)
Scroll down ↓ to “Low Flow Rate” Press → to enter menu
Notice the value that is displayed.
Use ← Key and → Key to toggle back and forth between digits.
Change the value using ↑ or ↓
Enter the value of the process (Example 0.0000 Gal per minute).
Press The F4 Key to enter and store the value.
Press the F3 Key (Home) to return to the Main Menu.
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow
Gauge
Low Reference
→
Low Flow Rate
Cal
.
Low Flow Rate 0.000
Ref Cap Value 20000
HOME
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Calibration
State Fully Calibra
Ref Constants
Cal Density
→
Cal Flow Rate
Temp Reference
Cal Remote Solids
Last Ref.Date
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Cal Flow Rate
State
→
Low Reference
High Calibrate
Manual Entry
Clear Ref/Cal
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Low Reference
WARNING – Remove
loop from automatic
control before doing
reference procedure.
ABORT OK
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Low Reference
Low Flow Rate Cal
→
Low Flow Rate 0.000
Ref Cap Value 18754
HOME
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Ref Density
0.0000 Gal per min
0.0000
ESC ENTER
