Installation
Page 12 RES-403 Version 1
5.5.1 PEX-W4
5.5.2 PEX-W5
Mounting on DIN-rail 35 x 7.5 mm or 35 x 15 mm (DIN EN 50022).
Snap-on for DIN-rail 35 x 7.5 mm or 35 x 15 mm (DIN EN 50022)
terminal
block
terminal
wires
14
60
24
75
14
23
28
26
39
12
