Dimensions
Page 44 RES-403 Version 1
9 Dimensions
10 Modifications (MODs)
Owing to its universal design, the RESISTRON
®
temperature controller RES-403 is suitable for a very wide range
of heatsealing applications.
Various modifications (MODs) are available for the RESISTRON
®
temperature controller RES-403 for imple-
menting special applications.
The modifications described here are just a few of the large number available. Separate documents are supplied
for all modifications.
The modifications must be ordered separately.
MOD 01
Amplifier for low secondary voltages (U
R
= 0.25…16VAC). This modification is necessary, for example, for very
short or low-resistance heatsealing bands.
MOD 26
Additional terminal for connecting an external switching amplifier (booster). This modification is necessary for high
primary currents (continuous current > 5A, pulsed current > 25A).
75.0 90.0
113.0
135.0
