Controller functions
Version 1 RES-403 Page 29
The "OUTPUT" LED blinks repeatedly when the "AUTOCOMP" function is executed and the actual value
output (terminals 17+14) is set to 0…3°C (i.e.approx. 0VDC).
3. „AUTO“
(as of software revision 108)
With this setting the „AUTOCOMP“ function is activated automatically after the "AUTOCAL" function has been
successfully executed.
Function
AUTOCAL
signal
"AC"
t
t
0
0
AUTOCAL
lit
t
OFF
<2.0s
AUTOCOMP
"AUTOCAL"
t
OFF
LED
lit
"OUTPUT"
LED
"AP"
24VDC
