Controller functions
Page 30 UPT-606
9.7 Parameter data
The parameter data contains values for selecting the
heatsealing element alloy, the temperature range, the
upper and lower tolerance band limits for temperature
monitoring, the calibration temperature and the optional
heating time limit. It is transferred from the PROFIBUS
master to the UPT-606 each time the system is started
up. If the parameter data is changed during operation,
the UPT-606 performs a reset. The PROFIBUS com-
munication is not interrupted. The parameter data has
the following structure:
No. Function
De-
fault
value
1
Possible
values
0…3 Reserved, set to 0 0 0
4 Temperature range /
alloy
10 0, 1, 4, 5, 8,
10
5 Lower temperature
OK threshold
10K 3…99K
6 Upper temperature
OK threshold
10K 3…99K
7 Calibration tempera-
ture
20°C -1, 0…40°C
8 Heating time limit
(100ms units)
0 0…99
(0…9.9s)
9 Extended controller
dignostis
acti-
vated
deactivated,
activated
10 Measuring impulse
duration
17 17…30
(1.7…3.0ms)
11 Data format High/
Low
byte
(Intel)
High/Low
byte (Intel),
Low/High
byte (Moto-
rola)
12 Correction factor Co 100% 25…200%
13/
14
Maximum
start temperature
100°
C
20…500°C
15 Error code format 4 bit 4 bit, 10 bit
16/
17
Temperature
cefficient
1700
ppm
400…4000
ppm
18 Temperature range 300°
C
200, 300,
400, 500°C
19/
20
Maximum
temperature
300°
C
200…500°
C
21 Temperature
diagnosis
de-
acti-
vated
deactivated,
activated
22/
23
Temperature dia-
gnosis delay time
(10ms steps)
0s 0…999
(0…9.99s)
24/
25
Heatup timeout
(10ms steps)
0s 0…999
(0…9.99s)
26 „TO“ bit
(Temperatur OK)
active
if
Tact
=
Tset
off,
active if
Tact =Tset ,
active if
Tact =Tset
with latch
27 Hold mode off off,
on,
2s
1. The default value is stored in the device
master file and transferred from the PRO-
FIBUS master to the UPT-606 when the
system is started up.
No. Function
De-
fault
value
1
Possible
values
