Technical data
Page 8 UPT-606
5 Technical data
Type of construction Housing for installation in the electrical cabinet
Snaps onto a standard top hat rail (DIN TS35 rail, 35 mm) acc. to DIN EN 50022
Dimensions: 90 x 75mm; height: 135mm (incl. terminals)
Line voltage As of software revision 100:
400VAC version: 380VAC -15%…415VAC +10% (equivalent to 323…456VAC)
Up to software revision 015:
400VAC version: 400VAC -15%…415VAC +10% (equivalent to 340…456VAC)
depending on version selected ( section 12 "How to order" on page 48)
Line frequency 47…63Hz, automatic adjustment to frequencies in this range
Auxiliary supply
Terminals 5+7 or PRO-
FIBUS plug,
pins 2+7
24VDC, Imax = 30mA
Tolerance: +10 / -10%
The auxiliary supply can be fed either via terminals 5 and 7 or via the PROFIBUS
plug at pins 2 and 7.
PROFIBUS-DP
interface
Baud rates: 9.6kbaud; 19.2kbaud; 45.45kbaud; 93.75kbaud; 187.5kbaud;
500kbaud; 1.5Mbaud; 3Mbaud; 6Mbaud; 12Mbaud
Plug acc. to IEC 61158
Heatsealing element
type and temperature
range
As of software revision 100:
The temperature range and temperature coefficient settings can also be specified
by means of the ROPEX visualization software ( section 9.11 "Diagnostic inter-
face/visualization software (as of software revision 100)" on page 39) in addition
to the rotary coding switch (see below):
Temperature range: 200°C, 300°C, 400°C or 500°C
Temperature coefficient: 400…4000ppm (variable setting range)
Two different ranges can be set with the rotary coding switch or via the PROFIBUS
interface:
Temperature coefficient 1700ppm, 0…300°C (CIRUS)
Temperature coefficient 1700ppm, 0…500°C (CIRUS)
Up to software revision 015:
One range can be set with the rotary coding switch or via the PROFIBUS interface:
Temperature coefficient 1700ppm, (optimized for ULTRA-PULSE-heatsealing
elements, 0…300°C
Analog output
(actual value)
Terminals 17+18
0…10V DC, Imax = 5mA
Equivalent to 0…300°C
Accuracy: ±1% add. 50mV
Alarm relay
Terminals 12, 13, 14
U
max
= 30V (DC/AC), I
max
= 0.2A, changeover contact, potential-free
Maximum load
(primary current of
impulse
transformer)
I
max
= 5A (duty cycle = 100%)
I
max
= 25A (duty cycle = 20%)
Power dissipation max. 20W
