2-7
Installation
FIGURE 2-6. Tri-Loop Wiring
Connections (Parallel Wiring).
Model 3095
I.S. Barrier (See Transmitter Manual
for I.S. Barrier Requirements)
250 Ω
Power
Supply
Pri-
mary
Sec-
ondary
Ter-
tiary
Fourth
Control Inputs
NON-HAZARDOUS AREA
3095/3095_08A
