3 Commissioning
OVERVIEW
This section summarizes procedures needed to commission the HART
Tri-Loop HART-to-Analog Signal Converter.
The following tasks are described in this section:
• Install the Tri-Loop Configurator software
• Configure the Tri-Loop
• Complete Burst Input Connection
• Perform system test
INSTALL THE TRI-LOOP
CONFIGURATOR
SOFTWARE
The HART Tri-Loop Configurator software package is available with or
without the HART modem and connecting cables (see page 5-1 for part
numbers). The complete Configurator package contains four 3.5-in.
floppy disks, one HART modem, and a set of cables for connecting the
computer to the HART Tri-Loop (see Figure 3-1).
FIGURE 3-1. Tri-Loop Configurator
Software Equipment.
Disk Containing HART
Tri-Loop Configurator
Software
Laptop Computer
(not included)
HART Modem and Cables
3095.tif
To Next Page
