Rosemount 333 HART Tri-Loop - Specifications and Reference Data; Ordering Information; Functional Specifications

Section
5-1
5 Specifications and
Reference Data
This section contains the following reference data for the HART
Tri-Loop HART-to-Analog Signal Converter:
• Ordering information
• Specifications
• Configuration Data Sheet (00806-0100-4754)
ORDERING
INFORMATION
NOTE
There are no user-serviceable parts for the HART Tri-Loop.
SPECIFICATIONS
Functional
Specifications
Service
Accessory product for the Model 3095 MV and Model 3244MV.
Output
One, two, or three 4–20 mA output signals,
user-selectable for DP, AP, GP, PT, or flow.
Power Supply
External power supply required for each channel. Channel 1 must be
powered for Tri-Loop operation. Each channel operates on terminal
voltage of 11–42.4 V dc.
Turn-on Time
Analog signals will be within specifications five seconds after power is
applied to Tri-Loop.
Installation Locations
Approved for FM ordinary locations.
Approved for CSA ordinary locations.
Model No.
(Part No.)
Description
Model 333U
(03095-0810-0001)
High Alarm Tri-Loop, Standard Configuration.
Model 333D
(03095-0810-0002)
Low Alarm Tri-Loop, Standard Configuration.
Model 333UC2
(03095-0810-0003)
High Alarm Tri-Loop, Custom Configuration.
Requires a completed Configuration Data
Sheet (00806-0100-4754).
Model 333DC2
(03095-0810-0004)
Low Alarm Tri-Loop, Custom Configuration.
Requires a completed Configuration Data
Sheet (00806-0100-4754).
03095-0821-0001 HART Tri-Loop Configurator Software–
Site License, HART Modem, Cables.
03095-0820-0002 HART Tri-Loop Configurator Software–
Site License.
03095-5105-0001 HART Modem and Cables.
