Rosemount 333 HART Tri-Loop - Configuration Data Sheet

5-3
Specifications and Reference Data
CONFIGURATION DATA
SHEET 00806-0100-4754
Complete this data sheet to define a custom configuration for the Madel 333 HART Tri-Loop.
Unless specified, the Tri-Loop will ship with the default values identified by the ★ symbol.
CONFIGURATION DATA SHEET
Customer: ______________________________________________________________________________
Customer P.O. No.: _____________________________________________________________________
Customer Line Item: _____________________________________________________________________
Model No. (select one) M High Alarm – Model No. 333UC2 M Low Alarm – Model No. 333DC2
(previously: 03095-0810-0003) (previously: 03095-0810-0004)
DEVICE INFORMATION (optional)
Tag: |___|___|___|___|___|___|___|___|
(8 characters)
Descriptor: |___|___|___|___|___|___|___|___|___|___|___|___|___|___|___|___|
(16 characters)
Message: |___|___|___|___|___|___|___|___|___|___|___|___|___|___|___|___|
|___|___|___|___|___|___|___|___|___|___|___|___|___|___|___|___|
(32 characters)
Date: |___|___| |___|___|___| |___|___|
(dd) (mmm) (yy)
CHANNEL 1
Channel Status (select one): M
Enabled M Disabled ★
Assigned Variable (select one)
(1)
: M Primary Variable M Secondary Variable ★
M Te r t i ar y Va r ia bl e M Fourth Variable
Variable Range: Zero (4 mA) Value _________________________
(2)
Full Scale (20 mA) Value ____________________
(2)
Variable Units ________________________________________
(2) (3)
(1) Verify process variable assignment for your instrument.
(2) This information must be completed for each enabled channel before the CDS can be accepted.
(3) Selected units must match device units or the Tri-Loop will alarm. Verify unit assignment for your instrument.
For RMD internal use only:
House Order No: __________________________
Line Item No: __________________________
Tri-Loop Serial No: __________________________
