3-5
Commissioning
FIGURE 3-4. Tri-Loop Wiring Connections
Model 3095
I.S. Barrier (See Transmitter Manual
for I.S. Barrier Requirements)
250 Ω
Power
Supply
Pri-
mary
Sec-
ondary
Ter-
tiary
Fourth
Control Inputs
NON-HAZARDOUS AREA
3095/3095_08A
