B-3
Appendix B
TABLE B-1. HART Fast Key
Sequences for the Tri-Loop.
Function
HART Communicator
Fast Key Sequences
Function HART Communicator
Fast Key Sequences
20 mA (Loop Test) 1, 2, 1, 2 Fld Dev Rev (Basic Setup) 2, 3, 8, 2
20 mA (Output Condition) 3, 1, 1, 1, 1, 2 Fld Dev Rev (Detailed Setup) 3, 2, 8, 2
4mA(LoopTest) 1,2,1,1 LRV(Calibration) 1,3,1,1,3
4 mA (Output Condition) 3, 1, 1, 1, 1, 1 LRV (Configure Channels) 2, 2, 1, 3
All (Calibration) 1, 3, 2, 4 Message (Basic Setup) 2, 3, 6
Burst Variable (Calibration) 1, 3, 1, 1, 1 Message (Detailed Setup) 3, 2, 6
Burst Variable (Configure Channels) 2, 2, 1, 1 Model (Basic Setup) 2, 3, 1
CH1 (Calibration) 1, 3, 2, 1 Model (Detailed Setup) 3, 2, 1
CH1(D/ATRIM) 1,4,1 NumReqPreams 3,1,2,2
CH1 (Output Condition) 3, 1, 1, 2, 1 Num Rsp Preams 3, 1, 2, 3
CH2 (Calibration) 1, 3, 2, 2 Other (Loop Test) 1, 2, 1, 3
CH2 (D/A TRIM) 1, 4, 2 Other (Output Condition) 3, 1, 1, 1, 1, 3
CH2 (Output Condition) 3, 1, 1, 2, 2 Poll Addr 3, 1, 2, 1
CH3 (Calibration) 1, 3, 2, 3 Proceed (Scaled D/A Trim) 3, 1, 1, 3, 1, 1
CH3 (D/A TRIM) 1, 4, 3 Reset 1, 1, 2
CH3 (Output Condition) 3, 1, 1, 2, 3 Software Rev (Basic Setup) 2, 3, 8, 3
Change (Scaled D/A Trim) 3, 1, 1, 3, 1, 2 Software Rev (Detailed
Setup)
3, 2, 8, 3
Date (Basic Setup) 2, 3, 4 Status 1, 1, 1
Date (Detailed Setup) 3, 2, 4 Tag 2, 1
Descriptor (Basic Setup) 2, 3, 5 Tag (Basic Setup) 2, 3, 3
Descriptor (Detailed Setup) 3, 2, 5 Tag (Detailed Setup) 3, 2, 3
Dev ID (Basic Setup) 2, 3, 2 Units (Calibration) 1, 3, 1, 1, 2
Dev ID (Detailed Setup) 3, 2, 2 Units (Configure Channels) 2, 2, 1, 2
Enabled (Calibration) 1, 3, 1, 1, 5 Universal Rev (Basic Setup) 2, 3, 8, 1
Enabled (Configure Channels) 2, 2, 1, 5 Universal Rev (Detailed
Setup)
3, 2, 8, 1
End(LoopTest) 1,2,1,4 URV(Calibration) 1,3,1,1,4
End (Output Condition) 3, 1, 1, 1, 1, 4 URV (Configure Channels) 2, 2, 1, 4
Final Asmbly Num (Basic Setup) 2, 3, 7
Final Asmbly Num (Detailed Setup) 3, 2, 7
