Quick Installation Guide
00825-0100-4663, Rev BC
December 2012
Rosemount 8732
5
Handle all parts carefully to prevent damage. Whenever possible, transport the system to
the installation site in the original shipping containers. PTFE-lined sensors are shipped with
end covers that protect it from both mechanical damage and normal unrestrained distortion.
Remove the end covers just before installation.
Figure 2. Rosemount 8705 Sensor Support for Handling
½- through 4-Inch Sensors
6-Inch and Larger Sensors
4663RevBCQIG.fm Page 5 Thursday, January 10, 2013 5:33 PM
