14 • Hardware Overview Ultripower User Guide (v4.0)
1. PSU OUT Ports 1 and 2
These ports are Molex mini-fit 4-position connectors that provide power drawn from both power supplies. Each
connector can support one connection to an Ultrix router.
2. PSU IN Port 2
This connection is the AC connector for the power supply module inserted in Slot 2.
3. 10/00 Ethernet Port
The Ethernet port is an RJ45 connector used to connect the Ultripower to an external Ethernet network. This port
is required for monitoring and control of Ultripower.
4. Reset and Restart Buttons
These buttons are not implemented.
5. PSU OUT Ports 3 and 4
These ports are Molex mini-fit 4-position connectors that provide power drawn from both power supplies.
6. PSU IN Port 1
This connection is the AC connector for the power supply module inserted in Slot 1.
Notice — The Ethernet ports do not provide Power-over-Ethernet (PoE).
