Ultripower User Guide (v4.0) Technical Specifications • 35
Technical Specifications
This chapter provides technical information for the Ultripower. Note that specifications are subject to change
without notice.
Physical Dimensions
General Specifications
 The C14 AC input connector is limited to 10amps. Therefore Ultripower is de-rated when powered from a source
less than 120VAC.
Environmental
Table 9.1 Physical Dimensions
Item Specifications
Width
(not including rack mounting ears)
17.5” (444.5mm)
Depth (chassis only) 8.1” (206mm)
Height 1.7” (43.2mm)
Weight (approx) Chassis + 1PSU 3.24kg (7.14lb)
1 PSU module only 1.59kg (3.51lb)
Table 9.2 General Specifications
Item Specifications
Inputs 90-240VAC
Positive Output 15VDC @ 300W per output connector
Maximum Total Output 1200W
On-board Cooling 4 x dynamically controlled fans
Table 9.3 Environmental Specifications
Item Specifications
Maximum Ambient Temperature Range 0°C to 40°C (32°F to 104°F)
Humidity <70% (non-condensing)
