18 • Physical Installation Ultripower User Guide (v4.0)
3. Connect the first power cable into the PSU socket marked 1 on the ULTRIX-FR2 rear panel.
4. Connect the second power cable into the PSU socket marked 2 on the ULTRIX-FR2 rear panel.
Connecting to an ULTRIX-FR5 Router
Each ULTRIX-FR5 router requires powering from an Ultripower Rack Mount Power Supply Unit.
 When using an Ultripower with an ULTRIX-FR5, the ULTRIX-FR5 must run Ultrix software version 3.43 or
higher.
To connect an Ultripower to an ULTRIX-FR5
1. Connect the ends of four power cables to the Ultripower rear panel OUT sockets.
2. Connect the free ends of the same power cables to the ULTRIX-FR5 rear panel.
3. Connect an AC power cable to the Ultripower PSU 1 socket.
4. If Ultripower is fitted with a second power module, connect a second AC power cable to the Ultripower PSU 2
socket.
Notice — The ULTRIX-FR2 router automatically powers on when power is applied to Ultripower.
Connect DC cables prior to connecting AC power source to Ultripower. This prevents the ULTRIX-FR2
from trying to draw too much power while only one DC cable is installed.
Notice — Powering an ULTRIX-FR5 from individual external power supplies is not supported.
Notice — Ensure that the power cable end with the ferrite bead connects to the Ultripower port.
(
Figure 4.4)
Notice — The ULTRIX-FR5 automatically powers on when power is applied to Ultripower. Connect DC
cables prior to connecting AC power source to the Ultripower. This prevents the ULTRIX-FR5 from trying
to draw too much power while only one DC cable is installed.
