ULTRIX-FR12 Installation Guide (v4.0) Technical Specifications • 49
Technical Specifications
This chapter provides technical information for ULTRIX-FR12. Note that specifications are subject to
change without notice.
Physical Dimensions
Inventory
Table 10 Technical Specifications — Physical Dimensions
Item Specification
Width 18.90” (48cm)
Depth 15.91” (40.41cm)
Height 21.0” (53.34cm)
Weight (approx.) 122lbs (55.34kg)
Table 11 Technical Specifications — Inventory
Item Specification
Video Matrix Size (max.) 288
Fixed I/O Slots 0
Optional I/O Slots 16 (288 x 288)
Audio
Audio Matrix Size (max.)
a
a. Assumes a chassis fully populated with SDI inputs.
4608 x 4608
Audio Matrix Size (with Optional MADI SFPs) 6144 x 6144
MultiViewer
Ultriscape Licenses per slot 3
Maximum Multiviewer Heads per System 48
UHD
UltriSpeed Licenses per frame 1
