56 • Technical Specifications ULTRIX-FR12 Installation Guide (v4.0)
Environmental
MicroSD Card
Ultriscape Output Specifications
Ethernet Port Connectors
Each ULTRIX-FR12 router comes standard with two Ethernet ports. Each port uses a standard single
8-pin, RJ45 connector to interface to an 802.3x Ethernet network. While ULTRIX-FR12 supports
1000Mbps (1GbE), 100Mbps, or 10Mbps network interface speeds, an 1GbE network connection is
required. The Ethernet ports are operated in a link aggregated or bonded configuration to provide
failover functionality.
 An 1GbE network connection is required.
Specifications
Supported USB-Serial Converters
The following USB-Serial chip-sets are supported:
• FTDI
Table 18 Technical Specifications — Environmental
Item Specifications
Max. Ambient Temperature Range 0°C to 40°C (32°F to 104°F)
Humidity, non-condensing < 95%
Table 19 Technical Specifications — MicroSD Card
Item Specifications
Types Supported Contact Ross Technical Support
Operating Systems
Supported
Table 20 Supported Video Formats
Format
Ultriscape Output
1080i 50Hz
1080i 59.94Hz
1080p 50Hz
1080p 59.94Hz
Table 21 Technical Specifications — Ethernet Ports
Item Specifications
Standards Accommodated 1000BASE-T (GbE) network
Connector Type RJ45
