Ross ULTRIX-FR12 - Output Signal Specifications

ULTRIX-FR12 Installation Guide (v4.0) Technical Specifications • 55
Outputs
Embedded Audio
Equalization (typical) UHD: 50m (160ft)
HD, 3G: 200m (650ft)
SD: 400m (1300ft)
SFP AUX Connector Refer to “Supported SFP Modules” for a list of
AUX options.
Refer to the Ultrix SFP Modules Guide for more
information on these options.
Table 16 Technical Specifications — Outputs
Item Specification
Standard Output HD-BNC
Signal Type (SDI Formats) 270MB/s
1.5GB/s
3GB/s
12GB/s
Impedance 75ohm
Amplitude 800mV +/-10%
Rise and Fall Time 270MB/s: 400-800ps
1.5GB/s, 3GB/s: < 135ps
12GB/s: <45ps
DC Offset 0.0V +/-0.5V
Jitter <0.15UI up to 3G
<0.20UI 3G and 12G typical (<0.30UI max.)
Return Loss Per SMPTE 2082-1
SFP AUX Connector Refer to the Ultrix SFP Modules Guide.
Table 17 Technical Specifications — Audio Inputs
Item Specification
Audio Channels per SDI I/O 16
Audio Channels per MADI I/O Selectable 56 or 64
Table 15 Technical Specifications — Inputs
Item Specification
