Programming
AC-F/G4x Series Installation and Programming Manual 61
There are two methods to assign relay codes to users: a
standard method and a search method.
5.14.1 Relay Code Assignment using Standard
Method
To assign the relay code using Standard method:
1.
Enter Programming mode.
2.
Press 9 to enter Menu 9.
The left LED turns green and the right LED
turns orange.
3.
Enter the 3-digit user slot for code
assignment.
The left LED flashes green.
4.
Enter the assignment digit for the current user slot:
 1 activates the Lock Strike relay only default
 2 activates the Auxiliary relay only
 3 activates the Lock Strike and Auxiliary relays
If the assignment code is valid, the left LED stops flashing.
The controller is now waiting for another slot number.
Green
Orange
Green
Orange
9
Green
