AY-B9350 User Manual 15
2. Introduction
2.1. Features
l Multi-Modal product which can use both of face and fingerprint authentication functions.
l Tilting camera automatically trace face position.
l Since an illuminance sensor and a Dual Camera (Color & IR) are installed, face
recognition is impossible even in a dark place. Save log image which can be recognized.
l Can be used along with RF Card (EM Card; 125 kHz) and Smart Card (MIFARE Card;
13.56MHz) simultaneously.
l Simple self- authentication through face or fingerprint
- Face recognition and fingerprint recognition technology (Biometrics) are used for
the device. Therefore, risk of password forgetting, card or key missing or robbery
can’t be prevented. In addition, security is enhanced using one’s own biometric
information.
l Access control system through network (LAN)
- Since communication is made between fingerprint recognition device and
authentication server using TCP/IP protocol, expansion is easy because it can be
directly applied to the existing Network. Not only 10/100 Mbps Auto Detect secures
quick speed but also management and monitoring through network is easy and
simple.
l Various registration and authentication methods are provided
- Or / And combination of face, fingerprint, card and password is supported.
If it is set to ‘Or’, authentication will be regarded as successful if any of the
registered authentication methods is successful. If it is set to ‘And’, all registered
Authentication methods must be successful to regard authentication as to be successful.
Ex> Fingerprint, card or fingerprint, fingerprint and card, face or fingerprint or card
or password
2.2. Configuration Diagram
2.2.1. Exclusive Usage (Access)
DC12V Adapter
(DC12V, 3.5A)
Electric lock
(Lock+, Lock-, Monitor)
To Next Page
